Features & Benefits
- Combining the elegance of traditional styling with the precision and technology of modern day design
- Nickel finish
- Accurate flow control
- Thermostatic control to +/- 1 degree - even if the water pressure fluctuates
- Full thermal protection to prevent scalding in the event of hot or cold water shut off
- In the event of hot or cold water failure the valve will shut down to the relevant standard
- The unique cartridge is highly resistant to calcium build up - even in hard water areas
- Our valves are suitable for use with all systems: gravity fed pumped unvented high pressure or fully modulated combi-boilers
- Excellent flow rates - even at low pressure
- Our valves can deliver 5.5 litres per minute at 0.1 bar pressure
- The cartridge is fully reversible meaning if hot and cold supplies are the wrong way round it doesn't need re-plumbing
- Simply remove the cartridge turn 180° and replace
- Manufactured from solid brass
Details
Guarantee no. of years
1 Year
Brand
BC Designs
Colour
Nickel
Assembly Required
No
Cartridge Included
Yes
Control Type
Manual
Flow Rate 0.2Bar 1/m
4.5000
Flow Rate 0.5Bar l/m
13.0000
Flow Rate 1Bar l/m
18.5000
Flow Rate 2Bar l/m
26.0000
Flow Rate 3Bar l/m
33.0000
Handset Included
No
Head Included
No
Mount Type
Wall Hung
No. Of Handles
2
Operating Pressure
0.1 Bar
Pipe Centres
150
Product Depth
135 mm
Product Height
206 mm
Product Width
195 mm
Stain Rust Resistant
Yes
TMV2 Approved
No
TMV3 Approved
No
Valve Included
Yes
Valve Mount Type
Exposed Shower
WRAS Approved
NO
